美國CTI6230HB，CTI6230HC係列掃描振鏡出售，CTI6240H振鏡，劍橋6200係列振鏡代理商，CTI振鏡維修159-901-990-65顧先生。CTI振鏡體(ti) 積小，速度快，精度高，質量非常穩定，被廣泛運用於(yu) 激光打標，振鏡焊接，舞台演示，水晶內(nei) 雕，三維動態聚焦，醫療激光等領域。
        美國劍橋公司全名CambridgeTechnologyINC，簡稱CTI，成立於(yu) 1978年作為(wei) 一個(ge) 供應商，在生物醫學研究領域的儀(yi) 器儀(yi) 表產(chan) 品的開發商。當時他們(men) 建立技術創新，高品質的製造和客戶承諾CTI的標準。在努力實現的精度和準確度的最高級別的產(chan) 品，劍橋高速奠定了閉環振技術，現在是劍橋的獨家產(chan) 品重點的基礎。
劍橋科技公司成立，作為(wei) 一個(ge) 供應商，在生物醫學研究領域的儀(yi) 器儀(yi) 表產(chan) 品的開發商。在1978年，當時我們(men) 建立技術創新，高品質的製造和客戶承諾我們(men) 的標準。在努力實現的最高水平準確度可以達到我們(men) 的產(chan) 品，我們(men) 奠定了閉環振技術，現在是我們(men) 的獨家產(chan) 品重點的基礎。
       通過我們(men) 不斷致力於(yu) 研發和創新，我們(men) 已經開發了振鏡位置檢測器的設計和關(guan) 鍵技術專(zhuan) 利的進展。這些創新使我們(men) 能夠引進具有提高了精度，速度，性能和可靠性棒產(chan) 品在科學和OEM光學掃描解決(jue) 方案。我們(men) 的工程師與(yu) 我們(men) 的客戶群開發產(chan) 品的配置，易於(yu) 使用和集成端無縫集成到他們(men) 的具體(ti) 應用。我們(men) 的配套產(chan) 品種類齊全，致力於(yu) 客戶服務和持續的產(chan) 品的研究方提供優(you) 質，創新，並相信我們(men) 的客戶期望從(cong) 劍橋的技術保證。
       從(cong) 第一劍橋科技提供的產(chan) 品 - 所有的方式達到我們(men) 目前的產(chan) 品線 - 。我們(men) 的承諾，這些已在我們(men) 的振技術的世界領先的標準，我們(men) 感到自豪，我們(men) 是保持建立在價(jia) 值觀念 - 這些允許值使我們(men) 的客戶一次又一次的成功。
       2009年1月。市場和技術在光學掃描已加入為(wei) 您帶來的光學掃描解決(jue) 方案是最好的。從(cong) 應用程序的特定組件掃描頭的領導人，我們(men) 的綜合公司為(wei) 您提供無與(yu) 倫(lun) 比的掃描技術和最廣泛的模擬和數字組合掃描解決(jue) 方案
Model 6231HC Moving Magnet Closed Loop Galvanometer Based Optical Scanner（CTI6231HC係列掃描振鏡）


The 6231H supports apertures of 8mm, 10mm, 12mm, and 15mm. It is shown here with the C connector and a 10mm Y mirror.

Galvanometer Specifications
All Position Detector specifications apply with Cambridge Technology servo driver after a 30 second warm-up. All angles are in mechanical degrees. Consult manual for complete operating instructions.

Mechanical
Rated Angular Excursion: 40°
Rotor Inertia: 0.82 gm cm2 , +/-10%
Torque Constant: 1.11x105 dyne cm/amp, +/-10%
Maximum Rotor Temperature: 110° C
Thermal Resistance (Rotor to Case): 1° C/Watt, Max

Electrical/Drive Mechanism
Coil Resistance: 1.27 Ohms, +/-10%
Coil Inductance: 176 µH, +/-10%
Back EMF Voltage: 195 µV/degree/sec, +/-10%
RMS Current: 5.8 Amperes at Tcase of 50° C, Max
Peak Current: 25 Amperes, Max
Small Angle Step Response Time: 250 µs, with balanced load of 0.3 gm*cm2

Position Detector
Linearity: 99.9 %, Minimum, over 20 degrees, 99.5% Typical, over 40 degrees
Scale Drift: 50 PPM/° C, Maximum
Zero Drift: 15 µrad/° C, Maximum
Repeatability, Short Term: 8 microradians
Output Signal, Common Mode: 155 µA with AGC current of 30mA, +/-20%
Output Signal, Differential Mode: 11.7 µA/°, at common mode current of 155 µA, +/-20%

Model 6230H Moving Magnet Closed Loop Galvanometer Based Optical Scanner（CTI6230H係列掃描振鏡）


The 6230H galvanometer can be designed and optimized for speed, size, cost and accuracy with typical beam diameters of 8mm, 10mm, 12mm, and 15mm. It is shown here with a 10mm Y mirror.

Galvanometer Specifications
All Position Detector specifications apply with Cambridge Technology servo driver after a 30 second warm-up. All angles are in mechanical degrees. Consult manual for complete operating instructions.

Mechanical Specifications
Rated Angular Excursion: 40°
Rotor Inertia: 0.97 gm cm2, +/-10%
Torque Constant: 1.31x105 dyne cm/amp, +/-10%

Maximum Rotor Temperature: 110°C Thermal
Resistance (Rotor to Case): 0.80°C/Watt, Max

Electrical Specifications/Drive Mechanism
Coil Resistance: 1.07 Ohms, +/-10%
Coil Inductance: 173 uH, +/-10%
Back EMF Voltage: 229 µV/degree/sec, +/-10%
RMS Current: 7.1 Amperes at Tcase of 50°C, Max
Peak Current: 25 Amperes, Max
Small Angle Step Response Time: 250 µs, with 8mm Y Mirror, settled to 99% 250 µs, with 10mm Y mirror, settled to 99%

Position Detector
Linearity: 99.9 %, Minimum, over 20 degrees, 99.5% Typical, over 40 degrees
Scale Drift: 50 PPM/°C, Maximum
Zero Drift: 15 µrad/°C, Maximum
Repeatability, Short Term: 8 microradians
Output Signal, Common Mode: 155 µA with AGC current of 30mA, +/-20%
Output Signal, Differential Mode: 11.7 µA/°, at common mode current of 155 µA, +/-20%

Model 6240H Moving Magnet Closed Loop Galvanometer Based Optical Scanner（CTI6240H係列掃描振鏡）


The 6240H galvanometer can be designed and optimized for speed, size, cost and accuracy with typical beam diameters of 12mm, 15mm, 20mm, 25mm, and 30mm. It is shown here with a 12mm Y mirror.

Galvanometer Specifications
All Position Detector specifications apply with Cambridge Technology servo driver after a 30 second warm-up. All angles are in mechanical degree. Consult manual for complete operating instructions.

Mechanical Specifications
Rated Angular Excursion: 40°
Rotor Inertia: 2.4 gm cm2, +/-10%
Torque Constant: 2.0x105 dyne cm/amp, +/-10%
Maximum Coil Temperature: 110°C
Thermal Resistance (Coil to Case): 0.62°C/Watt, Max

Electrical Specifications/Drive Mechanism
Coil Resistance: 1.03 Ohms, +/-10%
Coil Inductance: 350µH, +/-10%
Back EMF Voltage: 346 µV/degree/sec, +/-10%
RMS Current: 8.2 Amperes at Tcase of 50°C, Max
Peak Current: 25 Amperes, Max
Small Angle Step Response Time: 300 µs, with 12mm Y mirror, settled to 99%#p#分頁標題#e#
350µs, with 15mm Y mirror, settled to 99%
650 µs, with 20mm Y mirror, settled to 99%

Position Detector
Linearity: 99.9 %, Minimum, over 20 degrees, 99.5% Typical, over 40 degrees
Scale Drift: 50 PPM/°C, Maximum
Zero Drift: 15 µrad/°C, aximum
Repeatability, Short Term: 8 microradians
Output Signal, Common Mode: 155 µA with AGC current of 30mA, +/-20%
Output Signal, Differential Mode: 11.7 µA/°, at common mode current of 155 µA, +/-20%
本公司直接代理銷售美國劍橋（CambridgeTechnologyINC）的各型號掃描振鏡並提供維修服務
